Craftsmanship to last a lifetime

Rough In

Gallery

Drain sytem for self washing grease hood

Cast iron Hub Drain in parking garage with indirect copper drain. Non combustible piping

Residential gas water heater with recirc system and expansion tank for thermal expansion

Under counter plumbing for coffee shop, expresso machine drain

Groundwork for back to back toilets, floor drain and waste stack cleanout

Commercial bathroom rough in, Under Test

Side by side tankless water heaters in series for restaurant

Laundry room Rough in plumbing

Three bay sink Dishpit industrial Roastery and restaurant

Side view Roastery sink and water heater

Below slab plumbing for Tenant Improvement upper floor

Underfloor custom bath remodel

Cast Iron Cradle suspended for Post tension slab

No hub pipe suspended for Post tension slab

Grease interceptor suspended for Post tension slab

No hub pipe (for stability) cradle hangers above slab

Avoiding multiple cores Post tension

plumbing pipe suspended above slab. Insulation and top slab

Ground work plumbing residential

Replumbing lifted house

Plumbing lifted house before new foundation is set

Tankless water heater with re-circulation for restaurant

Self scouring wash down grease hood plumbing

Scullery sink commercial plumbing

Commercial water heater and reduced pressure backflow device Air Gap Drain into mop sink receptacle

Plumbing Ground work cafe

Plumbing ground work grease interceptor cafe coffee shop

Whole house filtration system

Restaurant plumbing Indirect lines into hub drain at sink

Cafe restaurant grease management after floor is sawcut for tenant improvement

Residential tankless water heater install Rheem

Underslab plumbing drains Groundwork ABS
